Outside Stator Motor AC Motor Winding Machine Scooter Single Wire Coil Winder
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Copper Wire: | Single Or Muti Wires | Wire Diameter: | Single Wire 0.1mm To 0.6mm (AWG22~AWG38) |
|---|---|---|---|
| Stator Type: | Outside Brushless Stator | Winding Type: | Flyer Winding,not Needle Winding |
| Human-Machine Interface: | Diagnose Show On CNC Screen | Operation Method: | Step, Auto, JOG |
| High Light: | coil making machine,stator coil winding machine |
||
Outside Stator Motor Flyer Winding Machine Scooter Single Wire Coil Winder
Application:
Armature flyer winding, Bicycle motor generator stator,
Airplan toy stator winding for single wire and parallel wires
Competitive Advantages:
1.Mass production yield,1200pcs output per shift for a OD 72.8mm bicycle generator stator
2.High passing rate, 99.9% good winding quality passing rate, stable and high efficiency
3. Fully automatic winding machine, winding,indexing,arrangment wire, clamping,cutting
Parameter Data:
| Item No. | Data |
| Wire diameter | 0.10~0.60mm (AWG22~AWG38) |
| Operation option |
Fully Automatic winding, automatic indexing, automatic winding arranging, automatic clamping and cutting |
| Stator slot no. | 2 to 24slots |
| Stator stack height | 5~50mm (0.197''~1.969'') |
| Stator outside diameter | 20~140mm (0.78'' ~5.5'') |
| Wire displacement | 60mm(2.36’’) |
| Power supply | AC220V 50/60Hz |
| Weight | about 350KGS |
| Dimension | 1260(L)x650(W)x1150(H)mm |
Information needed for Flyer Winding Machine inquiry:
1. Stack lamination drawing
2. Wire size, turns no.
3. Winding configuration
