CE Armature Winding Machine Dc Commutator Motor Fully Automatic Production Line
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Condition: | New | Armature Type: | Power Tool, Vacuum Clearner,car Motor Armaure |
|---|---|---|---|
| Com Bars: | 12 Bar, 24 Bar, 36bar | Automation Type: | Fully Automatic |
| Convey Type: | Three Types Convey Avialable | After Sales: | Engineering Team Available For Oversea Service |
| High Light: | armature coil winding machine,rotor winding machine |
||
Universal Dc Commutator Motor Armature Fully Automatic Production Line
S3 belt-convey armature production line is designed for ensuring high production efficiency, consistence quality of motor armature. Each machine in the line takes armature automatically from the belt, same function machine has separated conveyer to ensure the max production efficiency distribution, each machine operates with 7’’—10.4’’ touch screen. Equipped with special purpose reading-writing coder and magnetic card unit, it could identify armature status and process.
Process 1:
Shaft pressing→end shield pressing→commutator pressing→insulation paper inserting→armature
winding and fusing(1) →armature winding and fusing(2) →armature winding and fusing(3) →wedge blade
inserting→testing
Process 2:
Armature trickle impregnation
Process 3:
Commutator turning and cleaning→armature balancing→testing
Please click below link to view video
